SY225C

Medium Excavator

The SANY SY225C Medium Excavator matches the SY215C LC’s 163.6 horsepower and 21’8″ dig depth at a heavier 54,013 lb operating weight, with a reinforced undercarriage and heavier counterweight built for running a hydraulic hammer, shear, or grapple where stability under a swinging load matters more than digging alone.

The SY225C’s extended track-to-surface length of 12’7″ adds ground contact for working on soft or freshly graded fill, and its quick coupler plumbing keeps attachment changes fast between jobs.

Every SANY SY225C Medium Excavator carries SANY’s 5 year, 5,000 hour warranty.

Features

• 21’8″ dig depth
• 54,013 lb operating weight
• 163.6 HP
• Extended Track-to-Surface Length of 12’7″
• Reinforced Undercarriage and Heavier Counterweight
• Powerful Cummins Engine
• Quick Coupler Plumbing and Controls

Stop by SANY of Tulsa to see the SANY SY225C Medium Excavator on the lot.

Contact For More Info

Operating Weight

54,013 lbs

24,500 kg

Gross Power

163.6 hp

122 kW

Dig Depth

21' 8"

6,600 mm

Call for Pricing

Model	SY225C Medium
Boom Length	5,700 mm18' 8"
Stick (Arm) Length	2,925 mm9' 7"
Transport Length	9,728 mm31' 11"
Transport Width	3,390 mm11' 1"
Transport Height	3,370 mm11' 1"
Upper Structure Width	2,710 mm8' 11"
Cab Height	3,050 mm10' 0"
Blade Height	––
Track Width (standard shoe)	800 mm31"
Track Gauge	2,590 mm8' 6"
Ground Clearance (minimum)	480 mm19"
Tail Swing Radius	2,890 mm9' 6"
Track Length on Ground	3,830 mm12' 7"
Track Length	4,636 mm15' 3"

Model	SY225C Medium
Operating Weight	24,500 kg54,013 lb
Ground Pressure	36.1 kPa5.2 psi
Engine	Cummins QSB6.7
Displacement	6.7 L408.9 in³
Gross Power	122 kW163.6 HP
Hydraulics	Positive Flow with Pilot Control
Main Hydraulic Pump	Axial Piston – Variable Displacement
Operating Flow (maximum)	444.0 L/min117.3 gal/min
Operating Pressure (maximum)	34.3 MPa4,975 psi
Power Boost Pressure (maximum)	––
Travel Motor	Axial Piston with Park Brake
Travel Pressure (maximum)	34.3 MPa4,975 psi
Travel Speeds (maximum)	3.3 / 5.1 km/hr2.1 / 3.2 mph
Travel Effort (maximum)	180.0 kN40,466 lbf
Grade Capability	35°
Swing Motor	Axial Piston with Swing Brake
Swing Pressure (maximum)	28.0 MPa3,989 psi
Swing Speed (maximum)	10.9 rpm
Undercarriage (standard)	Steel Track
Track Shoe Width (standard)	800 mm31"
Track Rollers (per side)	9
Carrier Rollers (per side)	2

Model	SY225C Medium
Boom Length	5,700 mm18' 8"
Stick (Arm) Length	2,925 mm9' 7"
Maximum Digging Height	9,180 mm30' 1"
Maximum Dumping Height	6,670 mm21' 11"
Maximum Digging Depth	6,600 mm21' 8"
Maximum Vertical Wall Digging Depth	5,980 mm19' 7"
Maximum Reach at Ground Level	10,307 mm33' 10"
Maximum Swing Radius	3,730 mm12' 3"
